Jakarta ETFE Canopy

Entrant: Fabritecture (Designer and Installer)

Location: Jakarta, Indonesia.   Completed: June 2015  Client: Leightons Asia
Team: Denton Corker Marshall, Maffeis Engineering, Fabritecture, Seele Covertex

Application: ‘Floating’ canopy suspended over a courtyard using a 2-layer ETFE cushion system, supported exclusively by stainless steel tie rods

This project was entered in the LSAA 2016 Design Awards (Medium Fabric Structures, 8128)

M6 Community Recreational Facility Description

As part of Transport NSWs upgrade to the M6 freeway Stage 1 development, new recreational facilities were developed to provide shade to the community in various areas including McCarthy and Brighton Reserve. As part of the McCarthy Reserve upgrade, Fabritecture was contracted for the design and construction of eight (8) structures to provide shade cover for recreational facilities over a playground. The structures feature both Gale Pacific 95 Mesh and architecturally perforated aluminium.

DESIGN / FABRICATION / INSTALLATION BRIEF

Transport for NSW is delivering new recreational facilities for the Bayside Community before construction begins on Stage 1 of the M6 motorway in Rockdale, NSW. Fabritecture was contracted for 8 structures for installation at McCarthy Reserve. The structures are a combination of mesh shade structures clad with Gale Pacific Commercial 95 Heavy shade cloth, and aluminum architectural metal structures with custom artwork perforations in the panels.

STRUCTURAL SYSTEMS

The aluminium structures feature a steel frame with a grid system for the aluminium. The perforated panels are underslung, so the custom perforated artwork can be seen clearly from underneath the structures in the playground.

The shade structures are also steel framed and are tensioned using a Fabritecture extrusion system.

MATERIALS

The chosen material for the shade structures was Gale Pacific Commercial 95 340 Mesh, in 4 colours: Aquatic Blue, Desert Sand, Yellow and Orange. The fabric was chosen based on the colour specifications from the client.

The aluminium panels for the architectural metal structures was 6mm thick with a Colourbond Monument equivalent RAL 7021 with custom artwork perforations.

FABRICATION

The aluminium artwork features custom perforations in the patterning of native flora such as bottlebrush, and flora such as birds and frogs. There are 6 mesh structures in total at McCarthy Reserve, with 4 having an 8m diameter, and 2 with an 11m diameter. The 2 aluminium structures are 11m and 17m in diameter.

COLLABORATION, CONSTRUCTION AND MAINTENANCE

The installation of the structures occurred over existing playground equipment. This required specific planning. Construction involved the installation of all columns first and preassembling of roof discs on the ground. These were then crane lifted into their final install position. There was no overhead install.

Gale Pacific Commercial 95 340 Mesh is used widely for projects that require maximum sun protection and strength. The durable mesh fabric has low maintenance requirements and a long life performance.

COSTS

The M6 Community Recreational Facility project was valued at approximately AUD$730k.

PROJECT CREDITS

Project Name: M6 Community Recreational Facility
Location: West Botany Street
City: Rockdale, NSW, 2216
GPS Location:   -33.955663, 151.146580
Completion Date: 12-Oct-21
Category (1-8): 2 – Medium structures
Entrant Name: Fabritecture
Address:  Unit 14/15 John Duncan Court, Varsity Lakes, QLD 4227
Telephone:   +61 7 5587 7000
Mobile:   +61 408 402 716
Email Address:  This email address is being protected from spambots. You need JavaScript enabled to view it.
Website Address: www.fabritecture.com
Entrant Type / Role: Designer / Fabricator / Installer
Project Client: Transport NSW
Project Architect: Design Inc.
Structural Engineer: Greenup Design Engineers; Cardno
Building Contractor: Ertech Pty Ltd
Fabricator(S): Confidential

Entrant: Oasis Tension Structures

• Location: East Boundary Rd, East Bentleigh

• Client: Glen Eira City Council; Completion Date: December 2011

Judges Comments:

"Advances the technology in insulated membranes"

"Rather idiosyncratic form which answers a functional challenge, has a bit of fun, and provides some identity to a facility not short of disparate elements"

Dreamworld Taipan Theme Park Entrance Canopy Description

The Steel Taipan ride at Dreamworld on the Gold Coast is the theme parks newest attraction. The AUD$32million roller coaster features a 1.2km track roller coaster and the Southern Hemisphere’s first triple launch system that launches the train forward, backwards, and then forwards again at a top speed of 105km/hr!

Fabritecture was contracted for the design & construction of a bespoke walkway canopy structure to shelter patrons as they wait in line for the Steel Taipan ride. The structure features custom printed Serge Ferrari PVC designed to match the architectural intent of the structure – to emulate the scales of a taipan snake!

This project was entered in the LSAA 2009 Design Awards (Cat 2, 2397)

Entrant: Oasis Tension Structures (Australia) Pty Ltd
Location: Hugh King Boulevard - Mildura VIC

Application: This large PVC structure was created to provide a spectacular shelter from which entertainment of all descriptions can operate under cover in the picturesque environment of the banks of the Murray River in Mildura.

DESIGN FABRICATION INSTALLATION BRIEF

The Kina building at Green School New Zealand was conceived as a groundbreaking educational facility, designed to embody sustainable and innovative principles. The client’s vision was for a building that would integrate biophilic design with neuroarchitecture, enhancing both cognitive function and emotional well-being. The challenge was to create a structure that not only supported Green School’s commitment to holistic education and environmental stewardship but also reflected a deep connection to nature.

In addressing the design brief, Fabric Structures focused on several key aspects. The project demanded the use of cutting-edge fabric materials that would contribute to both the aesthetic and functional goals of the building.

This project was entered in the LSAA 2007 Design Awards (#3197) "Medium Fabric Structures"

Entrant: Tattersall Engineering

Client: Aquinas College / J A Dodd     Architect: Designinc Adelaide (Geof Naim)
Structural Engineer: Tattersall Engineering (See SEMF 2015)
Specialist Consultant(s): Wade Consultants     Builder: Tecraft Pty Ltd
Fabricator(s): Horizon Sailmakers / C E Bartlett, Riband (Steel), A Noble & Son (Cables)

Application and Function(s) of Project:

The structure is a pivotal element in an $8m redevelopment of the main Aquinas College campus, which comprised a new library, Year 9 centre, canteen and arts centre as well as refurbishment of the old library as an IT, arts and careers centre. The Forum structure links and protects all the adjoining buildings, proving a substantial undercover area in the middle of the school which serves as a protected function centre, meals and play area, incorporates a stage with a protected auditorium area, and links with the existing gymnasium and sports centre building.

Entered in the LSAA 2007 Design Awards (Cat 2, #2007, Medium Fabric Structures)

Entrant: PT Binatama Akrindo
Client: PT Summarecon Agung Tbk.
Unit La Piazza
Architect: PT Binatama Akrindo Sarjono Sam
Structural Engineer: PT Binatama Akrindo Tensys
Builder: PT Binatama Akrindo
Fabricator(s): Atkins Fabrications Pty Ltd,
PT Binatama Akrindo - Tridome space frame system + steelwork

Application: Lightweight Roof Canopy Over Café and Exhibition Stage

Entrant: MakMax Australia - Designer
Location: Port Lincoln South Australia
Client: Kym Clarke Constructions
Architect: John Diekman Architects
Struct. Eng.: MakMax Australia
Others: Cost Management Partners
Builder: Kym Clarke Constructions
Fabricator: MakMax Australia

This project was entered in the LSAA 2009 Design Awards (Cat2, Medium Fabric Structures #2813)

No further details have been entered to date.

This project was entered in the LSAA 2011 Design Awards (Cat 2, 2321)

APPLICATION: Public space & market canopy

As part of a major revitalisation and landscaping project for the Whangarei City Town Basin, the local council approached FSS to design a permanent canopy structure for the recently closed John Street bridge.

The John Street Bridge was one of two original road bridges connecting the Northern and Southern shores of the upper Whangarei harbour and forms part of the City Town Basin.
